Description
FEATURES
- Fully automated control of testing process
- Gas or electric ignition according to ASTM D93, EN ISO2719
- Simple, user-friendly interface
- Installed testing methods ( ASTM A93 ( A, B & C), “quick search”)
- Built-in programs editor
- Automatic ignition and moving of test flame
- Motorized arm for moving of cover cup with sensors node and stirrer
- High accuracy of heating rate
- Automatic diagnostic system
- Glass-shelled Pt-100 temperature probe
- Built-in barometric pressure sensor
- 6” color LCD display with touch-screen
- Built-in powerful fan
- 8Gb of internal memory
- USB-port for external storage device or printer
- LAN-port for connection to PC or internal network (LIMS)
- Automatic gas valve
- Universal input gas socket and adapter for portable gas cylinders
TECHNICAL DATA
| Temperature range, °С | 0 … 400 |
| Ignition type | gas/electric |
| Flash detector | thermocouple |
| Heating rate range, °С/min | 0,5 … 20,0 |
| Heating rate accuracy, °С/min | ±0.5 |
| Ignition interval, °С | 0,5 … 10 |
| Stirring spin rate, min-1 | 30 … 250 |
| Supply voltage, V/Hz | 220/50 |
| Power consumption, W | 700 |
| Dimensions, mm | 465x340x390 |
| Weight, kg | 15 |
